Z Stages

LV-143

1
Long working precision Z stage 60 x 115
Estimate separately
Travel +/-25 mm
Table size 60 mm x 115 mm
YESRoHS対応状況

Product documentation

Description

Z stage by using a V-groove and cross rollers (V-CR method) for the moving guide.
A rack and pinion is used for the transfer method to achieve a long travel.
It is widely used for precision positioning applications such as cameras and sensors.
It can be fixed in any position using a lever type clamp with high holding power.
Since precise positioning is possible, it can also be used as a focusing unit for microscopes, etc.

Specifications

Direction of travel Z axis one direction
Table size 60 mm x 115 mm
Clamp method Lever type
Mounting position Side
Transfer mechanism Rack and pinion
Travel +/-25 mm
Lead of actuator Coarse approx. 6 mm, fine approx. 0.68 mm
Scale interval Vernier reading 0.05 mm
Guiding method V-groove and cross rollers
Travel accuracy Straightness 0.01 mm
Load capacity 98 N (10㎏f)
Weight 1.6㎏
Material / Surface treatment Aluminum alloy/Black Alumite
Standard accessories Mounting screw : Hexagon socket head cap screw M4, 4 screws
