Z Stages

LV-111

1
Long working Z stage 40 x 50
Estimate separately
Travel 0 to 60 mm
Table size 40 mm x 50 mm
YESRoHS対応状況

Product documentation

Description

Z stage by using a douvetail groove (D-T method) for the moving guide.
A rack and pinion is used for the transfer method to achieve a long travel.
It is widely used for precision positioning applications such as cameras and sensors.

Specifications

Direction of travel Z axis one direction
Table size 40 mm x 50 mm
Clamp method Screw knob
Mounting position Double Handle Coarse
Transfer mechanism Rack and pinion
Travel 0 to 60 mm
Lead of actuator Approx. 18 mm
Scale interval Vernier reading 0.1 mm
Minimum resolution 0.1 mm
Guiding method Dovetail
Travel accuracy Straightness 0.08 mm
Load capacity 39.2 N (4 kgf)
Weight 0.76 kg
Material / Surface treatment Aluminum alloy/Black Alumite
Standard accessories Mounting screw : Hexagon socket head cap screw M4, 4 screws
