TD-C611

1
Two axis goniometer stage 60 x 60
Estimate separately
Travel Upper axis : +/- 8 °, lower axis : +/- 6 °
Table size 60 mm x 60 mm
YESRoHS対応状況

Product documentation

Description

Two-axis tilt stage.
Combine one-axis tilt stages with different rotation center heights to form a two-axis tilt stage with the same rotation center.
Our unique complex coupling mechanism enables fine and extremely smooth movements.
Dovetail groove (D-T method) is used for the moving guide.
It is widely used for positioning applications such as cameras and sensors.

Specifications

Direction of travel Tilt, two axis
Table size 60 mm x 60 mm
Clamp method Clamp plate
Transfer mechanism Precision screw, Composite coupling mechanism swivel
Travel Upper axis : +/- 8 °, lower axis : +/- 6 °
Lead of actuator Upper axis approx. 19' 59", lower axis approx. 15' 21"
Scale interval Vernier reading 6'
Guiding method Dovetail
Center of rotation 70 mm
Positioning accuracy of rotatation center -
Load capacity 39.2 N (4 kgf)
Weight 1.4 kg
Material / Surface treatment Blass/Black hard chrome
Standard accessories Mounting screw : Hexagon socket head cap screw M4, 4 screws
