| Direction of travel |
Tilt |
| Travel |
+/-10° |
| Table size |
125 mm x 125 mm |
| Motor |
PKP545N18B2 |
| Resolution |
0.002° |
| Transfer mechanism |
Worm gear mechanism |
| Guiding method |
V-groove and Cross roller |
| Positioning accuracy |
0.025° |
| Repeatability |
+/-0.002° |
| Stage height |
47 mm |
| Center of rotation |
160 mm |
| Positioning accuracy of rotatation center |
φ0.05 mm |
| Lost motion |
0.002° |
| Moment rigidity |
0.08sec/N*cm (Yaw), 0.03sec/N*cm (roll) |
| Load capacity |
98 N (10 kgf) |
| Weight |
2.7 kg |
| Maximum speed |
10°/s |
| Material / Surface treatment |
Aluminum alloy / White Alumite |
| HOME sensor |
Normally open contact (make contact, A contact) operation, Photo sensor
*non-adjustable |
| Pre-HOME sensor |
Normally closed contact (Break contact, B contact) operation, Photo sensor
*adjustable range : +/-10° |
| LIMIT sensor |
Normally closed contact (Break contact, B contact) operation, Photo sensor
*adjustable range : +/-10° |
| Compatible cable |
0.75-A type and 1.2-A type (ACB-BTD2, ACB-BTD3, ACB-BTD-D3, ARC-BTD3 or ARC-BTD-D3, be sold separately) |
| Standard accessories |
Inspection certificate
Mounting screw : M4 Hexagon socket head cap screws (4 pcs) |
| Supplemental note |
*Dedicated parameter setting for QT-A (Parameter No.4): 14 |
