| Number of controlled axes |
1 axis |
| Type |
Controller Options |
| Input power supply |
(May be damaged and all of these conditions are not met) that there is no such surge in less than 400mVp-p: within 10% DC24V ±, current capacity: over voltage range 2.5A, the allowable ripple voltage |
| Ambient Temperature and humidity |
10～40℃/20～80%（non-condensing） |
| Outside dimension |
W70mm×D80mm×H55mm（Excluding protrusions） |
| Weight |
0.5kg |
| Function |
Same company manufacture zaxis Motorized Stage with electromagnetic brakethe |
| Applicable models |
QT-BLD1, QT-BMM2, QT-BMH2, QT-BMM3, QT-ADL1, QT-ADM2, QT-AMH2A, QT-ADM3, QT-AMM3 and motoized stage with electromagnetic brake |
| Supplemental note |
※ When you intend to use the AC adapter, please use the dedicated ones always. |
