Stand

ES-20-100P

1
Stand φ20 L=100
Estimate separately
Diameter of the shaft fit φ20mm
YESRoHS対応状況

Product documentation

Description

This is a stand for 20mm diameter (shaft or pole). It is equipped with three clamp screw holes and can be clamped any clamp screw. Collar is adapted.

Specifications

Diameter of the shaft fit φ20mm
Height 100mm
Number of clamp screws 3 (apply from June 1, 2018)
Screws on the bottom M16P1
Weight 0.12kg
