TD-302

1
Tilt slim stage 30 x 30
Estimate separately
Travel +/- 3°
Table size 30 mm x 30 mm
YESRoHS対応状況

Product documentation

▲PAGE TOP

Description

Two-axis manual tilt stage with micrometer fine adjustment.
The ball between the upper stage and the base becomes the fulcrum of the tilt.
It is widely used for positioning applications such as cameras and sensors.
▲PAGE TOP

Specifications

Direction of travel Tilt, two axis
Table size 30 mm x 30 mm
Clamp method -
Transfer mechanism CMH-6.5FA (Standard micrometer head)
Travel +/- 3°
Lead of actuator Approx. 1°36'
Scale interval Micrometer head 0.01mm （1 scale approx. 1' 55"）
Load capacity 19.6 N (2 kgf)
Weight 0.06 kg
Material / Surface treatment Aluminum alloy/Black Alumite
Standard accessories Mounting screw : Hexagon socket head cap screw M2, 4 screws
