XY Motorized Stages for Microscopes

MSS-50WD-OA

0
Micro Scanning Stage
Estimate separately
Travel X axis +/-50 mm, Y axis +/-25 mm
Table size 205 mm x 155 mm
Compliant Microscopes Maker Olympus
YESRoHS対応状況

Product documentation

▲PAGE TOP

Description

Thin and light-weight motorized XY stage with 100 mm x 50 mm travel.
Suitable for microscope applications, it is thin and light-weight without compromising accuracy.
It can also be used as transmitted illumination by removing the standard aluminum plate and using an optional glass plate.
▲PAGE TOP

Specifications

Direction of travel XY axis two directions
Travel X axis +/-50 mm, Y axis +/-25 mm
Table size 205 mm x 155 mm
Motor PKP523N12A (5-wire type pentagonal connection 1.2 A/phase)
Resolution 0.002 mm
Feed screw Ball screw
Feed screw lead 1 mm
Guiding method V-groove and cross rollers
Travel accuracy Straightness 0.010 mm (horizontal), 0.015 mm (vertical)
Positioning accuracy 1/10stroke X axis:0.010 mm, Y axis:0.005 mm
Positioning accuracy fullstroke X axis:0.040 mm, Y axis:0.010 mm
Repeatability ±0.002 mm
Lost motion 0.002 mm
Load capacity 29.4 N (3 kgf）
Weight 3.3 kg (without Aluminum plate)
Maximum speed 40 mm/s (at 20,000 pps）
Material / Surface treatment Aluminum alloy/Black alumite
HOME sensor Normally closed contact (break contact, B contact）, Photo sensor
LIMIT sensor Normally closed contact (break contact, B contact）, Photo sensor
Compatible cable ACB-BTM2, ACB-BTM3, ARC-BTM3 (sold separately)
Standard accessories Aluminum plate
Adapter
Mounting screw for Adapter : Hexagon socket head cap screw M3, 4 screws
Compliant Microscopes Maker Olympus
Correspondence microscopes BH2
Supplemental note *Microscope adapter is included.
