SB-6002

1
Z bracket 60 mm x 60 mm
Estimate separately
Classification Z bracket
YESRoHS対応状況

Product documentation

Description

It is possible to attach an X stage and use it as a Z stage, to convert the plane of movement from vertical to horizontal, and to attach a rotary (rotation) stage to convert the rotation axis by 90°.
The T-shaped bracket can be installed on either the front or back side. Also, since the center of the load does not extend outside the outer shape of the bracket, there is no large unbalanced load.

Specifications

Classification Z bracket
Weight 0.2 kg
Material / Surface treatment Aluminum alloy/Black Alumite

Supplementation
