| Microscope tube |
Monocular viewing head with C-mount (0.7x), 3-hole revolving nosepiece |
| Objective |
M5X, M10X, M40X |
| Eyepiece |
WF10X, WF20X (replaceable) |
| Travel of microscope tube |
Front‐rear direction: 50 mm, Right-left direction: 30 mm |
| Focusing |
Coarse movement: 50 mm, Fine movement: 2 mm |
| Illumination |
White LED |
| Power supply |
LED reflected illumination (AA batteries x4) |
| AC adapter |
Dedicated AC adapter |
| Filter |
Yellow, green (replaceable) |
| Weight |
Main unit 4.6 kg, AC adapter 0.3 kg |
