Velnus

VELNUS-D3

1
Personal microscope
Estimate separately

Product documentation

Description

VELNUS is an inverted metallurgical microscope with built-in LED lighting.
A TV camera (C-mount) can be attached.
The sample stage is equipped with a table that can be moved in the XY-axis.

Specifications

Microscope tube Monocular viewing head, C-mount (main unit)
C mount 32 threads/25.4 mm, Flange focal length is 17.526 mm
Objective M5x, M10x, M40x
Eyepiece W10x
Stage Mechanical XY axis stage
Illumination Built-in White LED
Power supply LED reflected illuminator, AC adapter
Filter Yellow, green (replaceable)
Weight 5.7 kg
Accessory Vinyl cover, sample clamp, stage plate (bore diameter 15 mm), filters
