Rotary Stages

RS-612

1
Rotary stage φ62
Estimate separately
Table size φ62 mm
YESRoHS対応状況

Product documentation

▲PAGE TOP

Description

Rotary (rotation) stage by using a sliding guide for moving guide.
You can rotate the table 360 ??degrees by hand.
It is widely used for positioning applications such as cameras and sensors.
▲PAGE TOP

Specifications

Direction of travel Rotation
Table size φ62 mm
Travel 360° (coarse)
Scale interval Dial reading 1°
Guiding method Sliding
Load capacity 49 N (5 kgf)
Weight 0.2 kg
Material / Surface treatment Aluminum alloy/Black Alumite
Standard accessories Mounting screw : Hexagon socket head cap screw M4, 4 screws
