XYZ Rotary Stages

TR-4047-S1

1
High-Grade Aluminum XYZ Rotary stage 40 x 40 (Standard type)
Estimate separately
Travel XY axis +/-6.5 mm, Z axis 0~10 mm, Rotary axis coarse 360°fine +/-5°
Table size φ39 mm
YESRoHS対応状況

Product documentation

Description

This is an XYZ Rotary stage that combines a high-grade aluminum XY stage with a high-grade Z lift stage and high grade Rotary stage.
There are standard types and symmetrical types, and symmetrical configurations are also possible.
It is widely used for precision positioning applications such as cameras, sensors, and workpieces.

Specifications

Direction of travel XYZ, three axis and rotation
Table size φ39 mm
Clamp method XYZ axis clamp plate, rotary axis complex clamp
Mounting position XY axis side
Transfer mechanism XYZ axis CMH-13RM, Rotary axis CMH-6.5RA (each axis standard micrometer head)
Travel XY axis +/-6.5 mm, Z axis 0~10 mm, Rotary axis coarse 360°fine +/-5°
Lead of actuator XYZ axis 0.5 mm, Rotary axis approx. 0.99°
Scale interval XYZ axis  Micrometer head0.01mm,rotaryaxis Vernier reading10′/Micrometer head0.01mm(1 division approx0.020°)
Minimum resolution XYZ axis 0.003 mm
Guiding method XYZ axis HG-VCR (V-groove and cross rollers), Rotary axis sliding guide
Travel accuracy Straightness XY axis 0.002 mm, straightness Z axis 0.003 mm
Circularity 0.05 mm, deflection 0.02 mm
Load capacity 14.7 N (1.5 kgf)
Weight 0.50 kg
Material / Surface treatment XY Rotary axis Aluminum alloy/Black Alumite, Z axis Steel, Aluminum alloy/Black chromium oxide, Black Alumite
Supplemental note ※ For the Z stage is not symmetrical. For more information please check the external view of each product.
