TS-211

1
Goniometer stage 60 x 120
Estimate separately
Travel +/- 20°
Table size 60 mm x 120 mm
YESRoHS対応状況

Product documentation

▲PAGE TOP

Description

Long travel and high load capacity one-axis tilt stage.
By combining with the TS-611, which has different rotation center heights, you can create a two-axis tilt stage with the same rotation center.
Dovetail groove (D-T method) is used for the moving guide.
It is widely used for positioning applications such as cameras, sensors, and various experimental jigs.
▲PAGE TOP

Specifications

Direction of travel Tilt, one axis
Table size 60 mm x 120 mm
Clamp method Clamp plate
Transfer mechanism Worm gear
Travel +/- 20°
Lead of actuator Approx. 49'
Scale interval Vernier reading 5'
Guiding method Dovetail
Center of rotation 77 mm
Positioning accuracy of rotatation center φ0.1 mm
Load capacity 98 N (10 kgf)
Weight 1 kg
Material / Surface treatment Aluminum alloy/Black Alumite
Standard accessories Mounting screw : Hexagon socket head cap screw M4, 4 screws
